Delta UPS Amplon Family MX series Line interactive 1.1kva 2kva 3kva
UPS
Delta UPS Amplon Family MX series Line interactive 1.1kva 2kva 3kva
UPS
Reliable Power Protection for Small and Medium Business
The Amplon MX line-interactive UPS provides pure sine-wave quality
compatibility in versatile application in order to protect devices
and prevent small-and-medium businesses from power failure and
voltage variations in small footprint. The Amplon MX series
features enhanced output power factor 0.9, AVR Efficiency up to
96.5%, resulting in a greater power supply for critical loads at
significantly less operating cost.
Availability
• Microprocessor-based line interactive design for fast response to
power disturbances
• Programmable load bank disconnects non-critical loads when a
blackout occurs and reserves more battery power for critical loads
• Automatic voltage regulator (AVR) delivers stable output voltage
during brownouts or over-voltages
• Wide input voltage range allows the UPS to work in harsh
electrical environments
• Hot-swappable battery design to protect equipment during battery
replacement
Flexibility
- Supports both rack and tower installation
- Excellent management through a user-friendly graphical and
easy-shift LCD display to suit different installation format
- Supports multiple communication interfaces, including USB port, RS-
232, Mini Slot, Surge Protection, REPO for enhanced monitoring and
manageability
Low Total Cost of Ownership
• Output power factor is up to 0.9 to provide more real power to
critical loads
• High efficiency normal mode reach at 98% and 98.5% for 3kVA
• Wide input range and protection against over voltage prolongs
battery life
Tech Specification:
| Technical Specification |
| Model | | MX-1.1K | MX-2K | MX-3K |
| Power Rating | | 1100VA / 990W | 2000VA / 1800W | 3000VA / 2700W |
| Input | Voltage Range | 200Vac: 150-234Vac / 208Vac: 156-243Vac / 220Vac: 162-268Vac / 230Vac: 170-280Vac / 240Vac: 177-290Vac |
| Nominal Frequency | 50/60Hz (Auto-Detection) | |
| Connection | IEC C14 | IEC C20 | |
| Phase | Single phase with ground | |
| Output | Voltage | 200/208/220/230/240Vac | |
| Voltage Regulation | ±1.5% (Batt. Mode) | | |
| Frequency Range (Batt. Mode) | 50/60Hz ± 1Hz | | |
| Connection | IEC C13 (4+4) | | IEC C13 (4+4) IEC C19 (1) |
| Overload Capability | 103~120%: 5 minutes (1 minute @ Battery mode), 120~150%: 10
seconds, >150%: UPS shutdown immediately |
| Current Crest Ratio | 3:1 | | |
| Harmonic Distortion | Linear load (full load) ≤ 2%, Non-linear load (full load) ≤ 5% |
| Waveform (Batt. Mode) | Pure Sinewave | | |
| Battery | Battery Type | 12V/9Ah Sealed lead-acid battery | |
| Numbers | 2 | 4 | 6 |
| Recharge Time | 4 hours recover to 90% capacity | |
| Interface | Standard | RS-232 Port x 1, USB Port x 1, MINI Slot x 1, Surge Protection,
REPO |
| Efficiency | Normal Mode | 98% | | 98.5% |
| AVR Mode | 95.5% | 96.5% | |
| Environment | Operating Temperature | 0~40°C | | |
| Relative Humidity | 20~90% RH (non-condensing) | |
| Noise Level | < 45dBA | < 45dBA @ Normal mode, < 55dBA @ Battery mode |
| Physical | Dimensions (W x D x H) | 438 x 410 x 88mm | 438 x 510 x 88mm | 438 x 630 x 88mm |
| Net Weight | 14.1kg | 21.3kg | 32.1kg |
Solutions
We provide a complete solutions including site survey, propose
professional plan according to customer’s request ,technical
support, and maintenance service for Telecommunication Companies in
and out of China. We have a competent team and a network of trusted
Partners around the world.
FAQ :
1. How do you control the quality?
A:All products before the shipment are simulated usage scenarios,
load and full load and current sharing test to ensure the quality
of the product.
2. What is your minimum order quantity?
A:There is no minimum order quantity, and one can also be done. The
only difference is the price and schedule.
3. Can you introduce your company?
A:I am very honored. I will send you the company’s introduction
document later to give you a more comprehensive and direct
introduction to our company’s information.
4. What are the advantages of your company?
A:Adequate inventory, and supply guarantee for the subsequent
renewal of supply, flexible provided according to different to
different needs of customers, providing different solutions.
5. Can i send samples?Report it to me along with the price?
A:You can send samples, the samples are subject to large pride, and
the freight needs to be borne by you.
6. How do your company deal with the problem on quality?
A:Our company has been doing this industry for almost 10 years. It
has already had a certain reputation. We will carefully analyze it.
If it is indeed our quality problem, you can rest assured that it
will do things according to the contract agreement and will never
let you have any after the worries, our service team will be happy
to serve you.
7 What about the quality ?
A:100% original with new package. we will test each item before
posted to make sure each item with good quality.
8 How many months for guarantee ?
A: 1 year quality guarantee
9 How to deal with any inferior -quality goods ?
A: Goods can be post by with our charge of post fee for any bad
quality products within guarantee time.
