    19 Inch Pure Sine Weave Rack Mount Inverters BWT48/230-1KVA

    Ask Lasest Price
    Brand Name : BWT
    Model Number : BWT48/230-1KVA
    Certification : CE,UL
    Price : 499 USD/pc
    Payment Terms : L/C, T/T
    Supply Ability : 1000 pieces / month
    Delivery Time : 6-8 weeks
    • Product Details
    • Company Profile

    19 Inch Pure Sine Weave Rack Mount Inverters BWT48/230-1KVA

    19 Inch Pure Sine Weave Rack Mount Inverters BWT48/230-1KVA


    BWT Inverter Pure Sine Weave 48Vdc to 230Vac 1KVA 19 inch Rack Mount Inverters


    Feature:


    • Large 128*64 digital Lcd display data information,4 led display working;
    • 5 Routes Dry contact for system (DC input fault, AC input fault, overload information, by-pass information and output fault);

    Parameters :


    Technical Data
    ModelBWT48/230-1KVA
    INPUT
    Battery Input Voltage48Vdc
    Battery Voltage Range42-58Vdc
    DC Input Current23.8A Max
    Bypass Input Voltage230Vac Normal
    Bypass Voltage Range170~270Vac
    AC Input Frequency50Hz
    Frequency Range43~67Hz
    PF>0.8
    OUTPUT
    Output Capacity1000VA
    Rated Output Capacity800W
    Rated output Voltage230VAC (Inverter Mode)
    Rated Output Current3.47A
    Output Voltage Range230Vac(Tolerance ±1.5% @Inverter Mode)
    Output Efficiency≥85% (Inverter Mode)
    Output Frequency50Hz
    Output WavePure sine wave
    THD≤3% (Line Load)
    Switch Time (By pass to Inverter mode)≤5ms (With Load)
    PROTECTIVE FEATURE
    AC Under Voltage Switch Protection≤176Vac (Backlash voltage≥10Vac)
    AC over Voltage Switch protection≥264AC
    Over-TemperatureYes (Auto Switch)
    Battery under voltage protection point≤40VDC
    Battery Low-voltage alarm43VDC±0.5
    Battery overvoltage protection point≥60VDC
    Battery overvoltage recovery point≤57VDC
    Output Over Current Protection
    Over Load CapacityContinue working 60s @100%<load<120%
    Over Load CapacityContinue working 10s @ 121%<Load<150%
    Over Temp. ProtectionYes
    short circuit ProtectionYes (Don’t test under AC Connect)
    Reverse connection protectionYes
    Output OVP≥264VAC(Inverter Mode)
    Output low voltage alarm≤176VAC (Inverter Mode)
    SAFETY AND EMC
    Dielectric strength(AC-Chassis)3500Vdc/10mA//1min .No flash over, no breakdown, no arc (Only AC Input priority)
    Dielectric strength(DC-Chassis)

    750Vdc/10mA/1min. No flash over, no breakdown


    LVDEN 60950-1
    EMC/EM IEN 61000-6-3; EN 61000-6-1 ;IEC 61000-6-2 and IEC 61000-6-4

    ROHS


    IEC 62321-4 , IEC 62321-5,IEC 62321-6,IEC 62321-7,IEC 62321-8


    ENVIRONMENT TEST PERFORMANCE
    Ambient Temp.-20~ +50℃
    Cooling2*Fans
    High temperature operation50±2℃ (rated load 24H)
    Low temperature operation-20±2℃ (rated load 24H)
    High temperature storage80±2 ℃,24H
    Low temperature storage-40±2℃,24H
    Humidity0~90%,No moisture condensation
    Operating Altitude (m)Altitude Full power up to 2000m.derating -2% / 100m, max altitude 5000m
    COMMUNICATION
    Rs232 & Rs485Yes
    SNMPOptional
    Dry Contact5 group
    LCD DISPLAY

    LCD Status


    Input and output Voltage, Frequency, Output Current, Temp., Load Rate, LOGO etc.


    Inverter Status


    Normal Mains, Normal Inverter, Battery Under-voltage and output overload etc.


    MEASUREMENT
    Size W*D*H(mm)482mm *347mm*88mm (2RU)
    Weight11.5KG


    19 Inch Pure Sine Weave Rack Mount Inverters BWT48/230-1KVA

    19 Inch Pure Sine Weave Rack Mount Inverters BWT48/230-1KVA19 Inch Pure Sine Weave Rack Mount Inverters BWT48/230-1KVA19 Inch Pure Sine Weave Rack Mount Inverters BWT48/230-1KVA





    19 Inch Pure Sine Weave Rack Mount Inverters BWT48/230-1KVA19 Inch Pure Sine Weave Rack Mount Inverters BWT48/230-1KVA19 Inch Pure Sine Weave Rack Mount Inverters BWT48/230-1KVA

    19 Inch Pure Sine Weave Rack Mount Inverters BWT48/230-1KVA
    19 Inch Pure Sine Weave Rack Mount Inverters BWT48/230-1KVA
    Solutions
    We provide a complete solutions including site survey, propose professional plan according to customer’s request ,technical support, and maintenance service for Telecommunication Companies in and out of China. We have a competent team and a network of trusted Partners around the world.

    FAQ :
    1. How do you control the quality?
    A:All products before the shipment are simulated usage scenarios, load and full load and current sharing test to ensure the quality of the product.

    2. What is your minimum order quantity?
    A:There is no minimum order quantity, and one can also be done. The only difference is the price and schedule.

    3. Can you introduce your company?
    A:I am very honored. I will send you the company’s introduction document later to give you a more comprehensive and direct introduction to our company’s information.

    4. What are the advantages of your company?
    A:Adequate inventory, and supply guarantee for the subsequent renewal of supply, flexible provided according to different to different needs of customers, providing different solutions.

    5. Can i send samples?Report it to me along with the price?
    A:You can send samples, the samples are subject to large pride, and the freight needs to be borne by you.

    6. How do your company deal with the problem on quality?
    A:Our company has been doing this industry for almost 10 years. It has already had a certain reputation. We will carefully analyze it. If it is indeed our quality problem, you can rest assured that it will do things according to the contract agreement and will never let you have any after the worries, our service team will be happy to serve you.

    7 What about the quality ?
    A:100% original with new package. we will test each item before posted to make sure each item with good quality.

    8 How many months for guarantee ?
    A: 1 year quality guarantee

    9 How to deal with any inferior -quality goods ?
    A: Goods can be post by with our charge of post fee for any bad quality products within guarantee time.
