    Custom Made OEM Ups On Line 30KVA 40KVA 3 Phase In 3 Phase Out Rack Type

    Ask Lasest Price
    Brand Name : INVT
    Model Number : HR33 series
    Certification : CE,UL
    Price : 1 USD/pc
    Supply Ability : 1000 pieces / month
    Delivery Time : 6-8 weeks
    • Product Details
    • Company Profile

    Custom Made OEM Ups On Line 30KVA 40KVA 3 Phase In 3 Phase Out Rack Type

    Custom Made OEM Ups On Line 30KVA 40KVA 3 Phase In 3 Phase Out Rack Type

    ● 40kVA/40kW in 4U.


    ● 19'' cabinet available.


    ● Rack or tower installation.


    ● Up to 4 units in parallel.


    ● High efficiency up to 95.5%.


    ● Rack-mounted 3-phase UPS.


    ● Colorful Touch LCD.


    ● Optional Power Distribution & Battery Pack.



    MODELHR33010CLHR33015CLHR33020CLHR33025CLHR33030CLHR33040CL
    Power Rating10KVA/10KW15KVA/15KW20KVA/20KW25KVA/25KW30KVA/30KW40KVA/40KW
    Main
    Input3 P + N+ PE
    Rate Voltage380/400/415VAC (line-ine)
    Rate Frequency50/60Hz
    Input Voltage Range304~478Vac (line-ine),full load
    228V~304Vac (line-ine),full load; 228V~304Vac(line-ine),derate from 75% to 100% load
    Input Frequency Range40Hz~70Hz
    Input PF>0.99
    Input THDi<4% (100% Linear Load)<3% (100% Linear Load)
    Bypass
    Rate Voltage380/400/415Vac (line-ine)
    Rate Frequency50/60Hz
    Input Voltage RangeSelectable, -40%~+25%
    Bypass Frequency RangeSelectable, ±1Hz, ±3Hz, ±5Hz
    Bypass Overload125%, Long time;130%,10mins;150%,1min;>150%,1s
    Output
    Rate Voltage380/400/415Vac (line-ine)
    Rate Frequency50/60Hz
    Output PF1
    Output THDu<1% from 0% to 100% linear load
    <5.5% full non-linear load according to IEC/EN62040-3
    <1% from 0% to 100% linear load
    <5% full non-linear load according to IEC/EN62040-3
    Inverter Overload110% for 1 hour;125% for 10 min;150% for 1min;>150% for 200ms
    Battery
    Battery number±240VDC
    Charger Accuracy1%
    Charger Capacityup to 20% *Output power
    Battery Cold StartYes
    Efficiency
    AC Mode95.0%max95.5%max96.0%max96.0%max
    Battery Mode94.5%max95%max95.5%max95.5%max
    System
    DisplayLED + LCD+Touch Screen
    InterfaceRS232(only 10-25K), USB(only 40K), RS485, Programmable dry contact
    OptionSNMP,parallel kitSNMP,parallel kit,LBS
    Environmental
    Operation Temperature0 ~ 40 ℃
    Storage Temperature-40 ~ 70 ℃
    Relative Humidity0 ~ 95% Non condencing
    Noise (1 meter)65dB @ 100% load, 62dB @ 45% load
    Phisical data
    Dimension W*D*H (mm)438*780*130438*780*130438*700*174438*700*174
    Weigh (kg)25304141



    Custom Made OEM Ups On Line 30KVA 40KVA 3 Phase In 3 Phase Out Rack TypeCustom Made OEM Ups On Line 30KVA 40KVA 3 Phase In 3 Phase Out Rack TypeCustom Made OEM Ups On Line 30KVA 40KVA 3 Phase In 3 Phase Out Rack TypeCustom Made OEM Ups On Line 30KVA 40KVA 3 Phase In 3 Phase Out Rack Type

    Custom Made OEM Ups On Line 30KVA 40KVA 3 Phase In 3 Phase Out Rack TypeCustom Made OEM Ups On Line 30KVA 40KVA 3 Phase In 3 Phase Out Rack TypeCustom Made OEM Ups On Line 30KVA 40KVA 3 Phase In 3 Phase Out Rack Type

    Custom Made OEM Ups On Line 30KVA 40KVA 3 Phase In 3 Phase Out Rack Type
    Custom Made OEM Ups On Line 30KVA 40KVA 3 Phase In 3 Phase Out Rack Type
    Solutions
    We provide a complete solutions including site survey, propose professional plan according to customer’s request ,technical support, and maintenance service for Telecommunication Companies in and out of China. We have a competent team and a network of trusted Partners around the world.

    FAQ :
    1. How do you control the quality?
    A:All products before the shipment are simulated usage scenarios, load and full load and current sharing test to ensure the quality of the product.

    2. What is your minimum order quantity?
    A:There is no minimum order quantity, and one can also be done. The only difference is the price and schedule.

    3. Can you introduce your company?
    A:I am very honored. I will send you the company’s introduction document later to give you a more comprehensive and direct introduction to our company’s information.

    4. What are the advantages of your company?
    A:Adequate inventory, and supply guarantee for the subsequent renewal of supply, flexible provided according to different to different needs of customers, providing different solutions.

    5. Can i send samples?Report it to me along with the price?
    A:You can send samples, the samples are subject to large pride, and the freight needs to be borne by you.

    6. How do your company deal with the problem on quality?
    A:Our company has been doing this industry for almost 10 years. It has already had a certain reputation. We will carefully analyze it. If it is indeed our quality problem, you can rest assured that it will do things according to the contract agreement and will never let you have any after the worries, our service team will be happy to serve you.

    7 What about the quality ?
    A:100% original with new package. we will test each item before posted to make sure each item with good quality.

    8 How many months for guarantee ?
    A: 1 year quality guarantee

    9 How to deal with any inferior -quality goods ?
    A: Goods can be post by with our charge of post fee for any bad quality products within guarantee time.
