Proper DC Cable Routing

Figure 10 shows the proper cable routing for circuit breaker connections. All circuit breaker cables should be routed through the cable openings to the left, when looking at the rear of the shelf, of the connection points. NOTE: Routing the cables in any other manner may harm the personnel or the system.

Circuit 9 contains four circuit breaker and twenty GMT fuse connections. All DC output connections are accessible from the rear (Figure 12), whereas circuit breakers and fuses are accessible from the front (Figure 11).

Make GMT output and return connections by using the compression screws on the GMT terminal strips accessible from the rear (Figure 12). Select wire size according to specifications in the section “DC Output Requirements” on page 10. GMT cables should be routed straight down through the cable holes just below the GMT terminal block. Torque these M3 screws to 4.5 in-lbs. Install fuses into appropriate slots in the GMT fuse block shown in Figure 11. For load output and return circuit breaker connections (positions A and B), connect lugs to the double ¼” -20 studs with 5/8” centers, accessible from the rear, as shown in Figure 12. Circuit breakers can be found behind the distribution door on the right side of the system when viewing it from the front (Figure 11). Size wires and lugs according to specifications in the section “DC Output Requirements” on page 10. Breaker cables should be routed through the cable holes on the left side of the shelf when viewing it from the rear (Figure 10). DO NOT connect an equipment load to LVD-protected output connections.

Product Display

Delivery

Ding Ding Future Power Company provide professional solutions to the telecommunications and network power industries across Africa,the Middle East , South America and Southeast Asia clients.

we have grown rapidly since our inception in 2017 as a small company for telecom after-sale service for famous brands.

After several years development, we can supply several brands such as Vertiv, Eltek, ZTE, DPC, VAPEL, DELTA, CE+T,eNatel etc.

With rich experience for both AC and DC applications ,we offer turn key solutions that simplify project execution and procurement with a single point of contract. Treat us as an extension of your Telecom and IT facilites departments ready to help solve any type of power problem or complete a new power project together.

At the moment, we have 5 tech engineers and 15 skilled workers for produce indoor telecom cabinet, outdoor telecom cabinet, inverter system , inverter cabinet, big systems which used in telecom, base stations, railways , 4G/5G, industiral etc.

For any projects ,tender case, we will response in 72 hours; for small cases, we will response in 24 hours.

We welcome any clients around the world to inquiry with us at any time !
